Floor Mounted Charging Stations
I’m built to support most of American standard electric vehicles with the plug connector SAE J1772 (Type 1), the current is optional from 16 Amp to 40 Amp.
Smart
OCPP 1.6 or 2.0.1 is enable it to support software and remotely control the charging sessions.
Safe
Shockproof, over-temp protection, short circuit protection, over and under voltage protection, over load protection, ground protection, surge protection.
Durable
It’s built for long-time service, water proof and designed to work at -30 to 55 °C ambient temperature, never fear the freezing or the scorching heat.
OEM & ODM
Costumer can customized some features including the color, logo, functions , casing etc.
Technical Parameters
-
Charging Capacity
3.5kW, 7kW, 10kW
-
Power Input Rating
Single phase, 220VAC ± 15%, 16A ,32A and 40A
-
Output Plug
SAE J1772 (Type1) or IEC 62196-2 (Type 2)
-
Configurations
LAN (RJ-45) or Wi-Fi connection, Optional MID meter add-on
-
Operating Temperature
- 30 to 55 ℃ （-22 to 131 ℉） ambient
-
Protection Ratings
IP 65
-
RCD
Type A or Type B
-
Installation
Pole Mounted
-
Weight & Dimension
310*260* 95 mm (7kg) / 1400*200*100（8kg)
-
Certification
UL (Applying)
Features
-
Easy to install
Only need to fix with bolts and nuts, and connect the electric wiring according to the manual book.
-
Simple to charge
Plug & Charge, or swapping card to charge, or controlled by App, it depends on your choice.
-
Compatible with all EVs
It's built to be compatible with all the EVs with the type 1 plug connectors. Type 2 is also available with this type.
How to Install the Wallbox Charging Stations?
APPLICABLE DESTINATIONS
-
Parking Lot
Attract drivers who park longer and are willing to pay to charge. Provide convenient charge to EV drivers to max your ROI easily.
-
Retail &Hospitality
Generate new revenue and attract new guests by making your location an EV rest stop. Boost your brand and show off your sustainable side.
-
Workplace
Provide the charging stations can encourage the employees to drive electric. Set station access for only employees or offer it to the public.
